Print Height Image area up to 4”
Print Orientation Standard – Horizontal, Angled
Optional – Modular Top-Down
Mounting Angle 90º
Orifices/Channels 768/256
Lines of Print Up to 42 lines
Horizontal Resolution Selectable up to 300dpi
Throw Distance Up to ½” (12.7mm) for
Text Up to ¼” (6.4mm) for Barcodes
Operating Conditions Temperature: 50° - 104° F (10° - 40° C);
Relative Humidity: 20% - 80% (non-condensing)
Cable Lengths 2', 10', and 25'
Priming Automatic Priming System
Ink Delivery Dual Feed System
Sensors Float Switch Low Ink Sensor and Full Waste Bottle
Sensor Tied to Indicator Light on Printhead
Ink ScanTrue® II – Black, Red, Blue;
ScanTrue® II Plus – Black
Substrates Formulated for Porous Surfaces
Applications Formulated for High Contrast Barcodes, Logos,
Graphics and Text Messages
Drying Time Less than ¼ Second on Porous Surfaces
